| ITEM / MODEL |
RLT-1500 |
RLT-2000 |
HRT-2500 |
| Max. load in tons |
15 |
20 |
30 |
| Table sizes (mm) |
1500X1500 |
2000X2000 |
2500X2500 |
| Bearing diameter (outside/mm) |
1280 |
1600 |
1800 |
| Max. rpm R/T |
4.16 |
4.16 |
1.6 |
| Tilting moment (Nm) |
211.680 |
282.240 |
282.240 |
| Tangential moment, clamped (Nm) |
19.600 |
43.900 |
140.000 |
| Machining moment (Nm) (S1/S6) |
12.000 |
23.462 |
39.103 |
| W1 axis Stroke (mm) |
1500 |
1500 |
1500 |
| Linear axis feed rate (m/min) |
20 |
20 |
20 |
| Feeding force linear axis (N) |
25.000 |
25.000 |
25.000 |
| No. of guide rails |
2 |
2 |
4 |
| Parallelism between bottom and top surface |
0.0025 |
0.0025 |
0.0025 |
| Concentricity at center (mm) |
0.01 |
0.01 |
0.01 |
| ※ GSA remains the right of modification. All specifications can be modified according to customers’ requirement. |
