| ITEM / MODEL |
SLR-175 |
| Servo motor type |
FANUC |
α22 i / 3000 i |
| SIEMENS |
1FK7101 |
| Center-Hole Dia (mm) |
180H7 |
| Thru-Hole Dia (mm) |
100H7 |
| Gear Ratio |
1:90 |
| Min. Indexing Unit degree (degree) |
0.001° |
| Max. R.P.M. (rpm) (motor : 2000 / rpm) |
33.3 |
Hydro. Clamp Force (kg•m) (P:35kg / cm2) |
250 |
| Max. Machining Force (kg•m) |
160 |
| Indexing Accuracy Class (sec.) |
15" |
| Repeatability (sec.) |
Unidirectional |
2" |
| Bidirectional |
4" |
| Tilting degree |
-120°~120° |
| N.W. (kgs) (without spindle) |
300 |
| Dimension |
 |
| ※ GSA remains the right of modification. All specifications can be modified according to customers’ requirement. |
